[JAVA] ibatis를 mybatis로 변환하기

2021.05.19 - [K-digital training X 멀티 캠퍼스/프로젝트] - [UI/UX] Chatting_Area - 채팅창 구현

[UI/UX] Chatting_Area - 채팅창 구현

2021.05.19 - [K-digital training X 멀티 캠퍼스/프로젝트] - [JQUERY] AutoComplete - 검색 자동 완성 기능 [JQUERY] AutoComplete - 검색 자동 완성 기능 2021.05.19 - [K-digital training X 멀티 캠퍼스/프..

ktae23.tistory.com

기존 ibatis 프로젝트

java 프로젝트를 maven으로 변경하면서 pom에는 ibatis 대신 mybatis dependency를 추가한 상황

pom.xml

 <project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 https://maven.apache.org/xsd/maven-4.0.0.xsd">
  <modelVersion>4.0.0</modelVersion>
  <groupId>[프로젝트 이름]</groupId>
  <artifactId>[프로젝트 이름]</artifactId>
  <version>0.0.1-SNAPSHOT</version>
  <packaging>war</packaging>

  <dependencies>
      <!-- https://mvnrepository.com/artifact/org.aspectj/aspectjweaver -->
    <dependency>
    <groupId>org.aspectj</groupId>
    <artifactId>aspectjweaver</artifactId>
    <version>1.9.0</version>
    </dependency>

    <!-- https://mvnrepository.com/artifact/org.springframework/spring-context -->
    <dependency>
    <groupId>org.springframework</groupId>
    <artifactId>spring-context</artifactId>
    <version>5.2.9.RELEASE</version>
    </dependency>

    <!-- https://mvnrepository.com/artifact/javax.servlet/javax.servlet-api -->
    <dependency>
    <groupId>javax.servlet</groupId>
    <artifactId>javax.servlet-api</artifactId>
    <version>3.1.0</version>
    <scope>provided</scope>
    </dependency>

    <!-- https://mvnrepository.com/artifact/javax.annotation/javax.annotation-api -->
    <dependency>
    <groupId>javax.annotation</groupId>
    <artifactId>javax.annotation-api</artifactId>
    <version>1.3.2</version>
    </dependency>

    <!-- https://mvnrepository.com/artifact/org.springframework/spring-web -->
    <dependency>
    <groupId>org.springframework</groupId>
    <artifactId>spring-web</artifactId>
    <version>5.0.7.RELEASE</version>
    </dependency>

    <!-- https://mvnrepository.com/artifact/org.springframework/spring-webmvc -->
    <dependency>
    <groupId>org.springframework</groupId>
    <artifactId>spring-webmvc</artifactId>
    <version>5.0.7.RELEASE</version>
    </dependency>

    <!-- https://mvnrepository.com/artifact/org.springframework/spring-jdbc -->
    <dependency>
    <groupId>org.springframework</groupId>
    <artifactId>spring-jdbc</artifactId>
    <version>5.0.7.RELEASE</version>
    </dependency>

    <!-- https://mvnrepository.com/artifact/org.springframework/spring-jdbc -->
    <dependency>
    <groupId>org.springframework</groupId>
    <artifactId>spring-jdbc</artifactId>
    <version>5.0.7.RELEASE</version>
    </dependency>

    <dependency>
    <groupId>org.mybatis</groupId>
    <artifactId>mybatis</artifactId>
    <version>3.2.2</version>
    </dependency>

    <dependency>
    <groupId>org.mybatis</groupId>
    <artifactId>mybatis-spring</artifactId>
    <version>1.2.0</version>
    </dependency>

  </dependencies>

  <build>
            ...
  </build>
</project>

프로젝트가 구동하면 web.xml을 먼저 읽은 후 servlet을 읽어 온다.

web.xml

 <?xml version="1.0" encoding="UTF-8"?>
<web-app xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns="http://java.sun.com/xml/ns/javaee"
xmlns:web="http://java.sun.com/xml/ns/javaee"
xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://java.sun.com/xml/ns/javaee/web-app_2_5.xsd"
id="WebApp_ID"
version="2.5">

  <display-name>[프로젝트 이름]</display-name>

      <context-param>
        <param-name>contextConfigLocation</param-name>
        <param-value>
            /WEB-INF/spring-security.xml
        </param-value>
    </context-param>

  <servlet>
    <servlet-name>dispatcher</servlet-name>
    <servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class>
  </servlet>

  <servlet-mapping>
    <servlet-name>dispatcher</servlet-name>
    <url-pattern>*.do</url-pattern>
  </servlet-mapping>


</web-app>

web.xml에서 읽어들인 servlet인 dispatcher-sevlet에서는 bean을 정의한다

dispatcher-servlet

 <?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
    xmlns:context="http://www.springframework.org/schema/context"
    xmlns:mvc="http://www.springframework.org/schema/mvc"
    xmlns:p="http://www.springframework.org/schema/p"
    xmlns:aop="http://www.springframework.org/schema/aop"
    xmlns:util="http://www.springframework.org/schema/util"
    xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xsi:schemaLocation="http://www.springframework.org/schema/beans
       http://www.springframework.org/schema/beans/spring-beans-3.0.xsd
       http://www.springframework.org/schema/util
       http://www.springframework.org/schema/util/spring-util-3.0.xsd
       http://www.springframework.org/schema/mvc
       http://www.springframework.org/schema/mvc/spring-mvc-3.0.xsd
       http://www.springframework.org/schema/aop
       http://www.springframework.org/schema/aop/spring-aop-3.1.xsd
       http://www.springframework.org/schema/context
       http://www.springframework.org/schema/context/spring-context-3.0.xsd">

    <context:component-scan base-package="[패키지명].board.controller"/>
    <context:component-scan base-package="[패키지명].board.service"/>
    <context:component-scan base-package="[패키지명].init"/>
    <context:property-placeholder location="/WEB-INF/*.properties" />


    <!-- viewResolver -->
    <bean id="vewResolver"
        class="org.springframework.web.servlet.view.InternalResourceViewResolver">
        <property name="viewClass" value="org.springframework.web.servlet.view.JstlView" />
           <property name="prefix" value="/WEB-INF/" />
           <property name="suffix" value=".jsp" />
       </bean>

        <!-- iBatis -->
     <!-- JDBC 커넥트 관리 부분으로 config 패키지 하위 properties로 정보가 관리 되고 있었따.-->
    <util:properties id="config" location="classpath:config/dbconn.properties"/>
    <bean id="dataSource" class="org.apache.commons.dbcp.BasicDataSource" destroy-method="close">
        <property name="driverClassName" value="#{config['jdbc.driver']}"/>
        <property name="url" value="#{config['jdbc.url']}" />
        <property name="username" value="#{config['jdbc.username']}" />
        <property name="password" value="#{config['jdbc.password']}" />
    </bean>

    <bean class="org.springframework.beans.factory.config.PropertyPlaceholderConfigurer">
        <property name="locations" value="classpath:config/conn.properties;classth:config/database.properties" />
    </bean>

    <!-- ibatis 사용을 위한 SqlMapClient 팩토리 빈으로 바로 위 datasouorce 빈과 config 패키지 하위 sqlMapConfig 설정 xml을 참조 한다-->
       <bean id="sqlMapClient"
           class="org.springframework.orm.ibatis.SqlMapClientFactoryBean">
           <property name="dataSource" ref="dataSource" />
           <property name="configLocation" value="classpath:/config/sqlMapConfig.xml" />
       </bean>

       <!-- Dao classes -->
    <!-- Dao 클래스 사용을 위한 빈 생성-->
    <bean id="loginDao"
        class="[패키지명].login.dao.LoginDaoImpl"
        p:sqlMapClient-ref="sqlMapClient" />

     <bean id="memberDao"
         class="[패키지명].member.dao.MemberDaoImpl"
        p:sqlMapClient-ref="sqlMapClient" />

     <bean id="boardDao"
         class="[패키지명].board.dao.BoardDaoImpl"
        p:sqlMapClient-ref="sqlMapClient" />


</beans>

BoardDaoImpl

 package kr.co.openeg.lab.board.dao;

import java.util.HashMap;
import java.util.List;

import [패키지명].board.model.BoardCommentModel;
import [패키지명].board.model.BoardModel;

import org.springframework.jdbc.core.support.JdbcDaoSupport;
import org.springframework.orm.ibatis.support.SqlMapClientDaoSupport;


public class BoardDaoImpl extends SqlMapClientDaoSupport  implements BoardDao {

    private HashMap<String, Object> valueMap = new HashMap<String, Object>();


    @Override
    public List<BoardCommentModel> selectCommentList(int idx) {
        return getSqlMapClientTemplate().queryForList("board.getCommentList", idx);
    }

    @Override
    public void insertArticle(BoardModel board) {
            getSqlMapClientTemplate().insert("board.writeArticle", board);
    }

    @Override
    public void deleteArticle(int idx) {
        getSqlMapClientTemplate().delete("board.deleteArticle", idx);
    }

    @Override
    public BoardCommentModel selectOneComment(int idx) {
        return (BoardCommentModel) getSqlMapClientTemplate().queryForObject("board.getOneComment", idx);
    }

    @Override
    public void updateArticle(BoardModel board) {
           getSqlMapClientTemplate().update("board.modifyArticle", board);
    }

}

ibatis 메서드
- queryForObject : SELECT로 값을 가져올 때 사용, 데이터가 여러 행일 경우 자동으로 List 형태로 변환
- queryForList : SELECT로 값을 가져올 때 사용, 조건에 따라 데이터가 하나일 경우 quereyForObject를 사용
- insert
- update
- delete

참고 블로그

sqlMapConfig.xml

 <?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE sqlMapConfig
    PUBLIC "-//ibatis.apache.org//DTD SQL Map Config 2.0//EN"
    "http://ibatis.apache.org/dtd/sql-map-config-2.dtd">

<sqlMapConfig>
    <settings useStatementNamespaces="true"    />
    <sqlMap resource="[패키지명]/member/dao/member.xml" />
    <sqlMap resource="[패키지명]/board/dao/board.xml" />
    <sqlMap resource="[패키지명]/login/dao/login.xml" />
</sqlMapConfig>

매퍼 파일이 있는 위치를 지정해준다.
DOCTYPE이 sqlMApConfig이다.

board.xml

 <?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE sqlMap
    PUBLIC "-//ibatis.apache.org//DTD SQL Map 2.0//EN"
    "http://ibatis.apache.org/dtd/sql-map-2.dtd">

<sqlMap namespace="board">
        <typeAlias alias="BoardModel" type="[패키지명].board.model.BoardModel"/>
        <typeAlias alias="BoardCommentModel" type="[패키지명].board.model.BoardCommentModel"/>
            ...
<select id="loginCheck" parameterClass="String" resultClass="LoginModel">
            ...
    </select>


</sqlMap>

ibatis는 DOCTYPE과 최상위 태그가 sqlMap이다.
sqlMap의 namespace는 줄임말로 사용 가능
parameteClass와 resultClass를 사용한다
- 여기서 사용되는 model(VO,DTO)의 별칭은 typeAlias 지정을 통해 지정한다.

Mybatis 프로젝트

pom.xml

 <project xmlns="http://maven.apache.org/POM/4.0.0"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
https://maven.apache.org/xsd/maven-4.0.0.xsd">

  <modelVersion>4.0.0</modelVersion>
  <groupId>[프로젝트명]</groupId>
  <artifactId>[프로젝트명]</artifactId>
  <version>0.0.1-SNAPSHOT</version>
  <packaging>war</packaging>


  <dependencies>
    <dependency>
         <groupId>javax.servlet</groupId>
         <artifactId>jstl</artifactId>
         <version>1.2</version>
    </dependency>
    <dependency>
      <groupId>javax.servlet.jsp</groupId>
      <artifactId>javax.servlet.jsp-api</artifactId>
      <version>2.3.0</version>
      <scope>provided</scope>
    </dependency>
    <dependency>
      <groupId>javax.el</groupId>
      <artifactId>javax.el-api</artifactId>
      <version>2.2.2</version>
      <scope>provided</scope>
    </dependency>
      <!-- https://mvnrepository.com/artifact/org.aspectj/aspectjweaver -->
    <dependency>
    <groupId>org.aspectj</groupId>
    <artifactId>aspectjweaver</artifactId>
    <version>1.9.0</version>
    </dependency>

    <!-- https://mvnrepository.com/artifact/org.springframework/spring-context -->
    <dependency>
    <groupId>org.springframework</groupId>
    <artifactId>spring-context</artifactId>
    <version>5.2.9.RELEASE</version>
    </dependency>

    <!-- https://mvnrepository.com/artifact/javax.servlet/javax.servlet-api -->
    <dependency>
    <groupId>javax.servlet</groupId>
    <artifactId>javax.servlet-api</artifactId>
    <version>3.1.0</version>
    <scope>provided</scope>
    </dependency>

    <!-- https://mvnrepository.com/artifact/javax.annotation/javax.annotation-api -->
    <dependency>
    <groupId>javax.annotation</groupId>
    <artifactId>javax.annotation-api</artifactId>
    <version>1.3.2</version>
    </dependency>

    <!-- https://mvnrepository.com/artifact/org.springframework/spring-web -->
    <dependency>
    <groupId>org.springframework</groupId>
    <artifactId>spring-web</artifactId>
    <version>5.0.7.RELEASE</version>
    </dependency>

    <!-- https://mvnrepository.com/artifact/org.springframework/spring-webmvc -->
    <dependency>
    <groupId>org.springframework</groupId>
    <artifactId>spring-webmvc</artifactId>
    <version>5.0.7.RELEASE</version>
    </dependency>

    <!-- https://mvnrepository.com/artifact/org.springframework/spring-jdbc -->
    <dependency>
    <groupId>org.springframework</groupId>
    <artifactId>spring-jdbc</artifactId>
    <version>5.0.7.RELEASE</version>
    </dependency>

    <dependency>
        <groupId>commons-dbcp</groupId>
        <artifactId>commons-dbcp</artifactId>
        <version>1.4</version>
    </dependency>

    <dependency>
    <groupId>org.mybatis</groupId>
    <artifactId>mybatis-spring</artifactId>
    <version>1.3.2</version>
    </dependency>

    <dependency>
    <groupId>org.mybatis</groupId>
    <artifactId>mybatis</artifactId>
    <version>3.4.6</version>
    </dependency>

 <!-- Spring Security -->
    <dependency>
        <groupId>org.springframework.security</groupId>
        <artifactId>spring-security-core</artifactId>
        <version>4.1.3.RELEASE</version>
    </dependency>
    <dependency>
        <groupId>org.springframework.security</groupId>
        <artifactId>spring-security-web</artifactId>
        <version>4.1.3.RELEASE</version>
    </dependency>
    <dependency>
        <groupId>org.springframework.security</groupId>
        <artifactId>spring-security-config</artifactId>
        <version>4.1.3.RELEASE</version>
    </dependency>
    <dependency>
        <groupId>org.springframework.security</groupId>
        <artifactId>spring-security-taglibs</artifactId>
        <version>4.1.3.RELEASE</version>
    </dependency>


         <!-- https://mvnrepository.com/artifact/mysql/mysql-connector-java -->
    <dependency>
         <groupId>mysql</groupId>
         <artifactId>mysql-connector-java</artifactId>
         <version>8.0.22</version>
     </dependency>


  </dependencies>

  <build>
               ...
  </build>
</project>

web.xml

 <?xml version="1.0" encoding="UTF-8"?>
<web-app xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns="http://java.sun.com/xml/ns/javaee"
xmlns:web="http://java.sun.com/xml/ns/javaee"
xsi:schemaLocation="http://java.sun.com/xml/ns/javaee: http://java.sun.com/xml/ns/javaee/web-app_2_5.xsd"
id="WebApp_ID"
version="2.5">

  <display-name>[프로젝트명]</display-name>

      <context-param>
        <param-name>contextConfigLocation</param-name>
        <param-value>
            /WEB-INF/spring-security.xml
        </param-value>
    </context-param>

  <servlet>
    <servlet-name>dispatcher</servlet-name>
    <servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class>
      <init-param>
          <param-name>contextConfigLocation</param-name>
          <param-value>/WEB-INF/dispatcher-servlet.xml</param-value>
      </init-param>
      <load-on-startup>1</load-on-startup>
  </servlet>

    <servlet-mapping>
    <servlet-name>dispatcher</servlet-name>
    <url-pattern>*.do</url-pattern>
  </servlet-mapping>

</web-app>

dispatcher-servlet

 <?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
    xmlns:context="http://www.springframework.org/schema/context"
    xmlns:mvc="http://www.springframework.org/schema/mvc"
    xmlns:p="http://www.springframework.org/schema/p"
    xmlns:aop="http://www.springframework.org/schema/aop"
    xmlns:util="http://www.springframework.org/schema/util"
    xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xsi:schemaLocation="http://www.springframework.org/schema/beans
       http://www.springframework.org/schema/beans/spring-beans-3.0.xsd
       http://www.springframework.org/schema/util
       http://www.springframework.org/schema/util/spring-util-3.0.xsd
       http://www.springframework.org/schema/mvc
       http://www.springframework.org/schema/mvc/spring-mvc-3.0.xsd
       http://www.springframework.org/schema/aop
       http://www.springframework.org/schema/aop/spring-aop-3.1.xsd
       http://www.springframework.org/schema/context
       http://www.springframework.org/schema/context/spring-context-3.0.xsd">


    <!-- 어노테이션을 사용하기 위한 태그, 바로 윗 태그인 beans에 xmlns:mvc가 있어야 함-->
    <mvc:annotation-driven/>
    <!-- 스캔 할 컴포넌트(어노테이션)의 상위 패키지 명시 -->
    <context:component-scan base-package="[패키지명]"/>


    <!-- viewResolver -->
    <bean id="viewResolver"
        class="org.springframework.web.servlet.view.InternalResourceViewResolver">
        <property name="viewClass" value="org.springframework.web.servlet.view.JstlView" />
           <property name="prefix" value="/WEB-INF/" />
           <property name="suffix" value=".jsp" />
       </bean>


    <!-- dataSource는 동일-->
    <util:properties id="config" location="classpath:config/dbconn.properties"/>
    <bean id="dataSource" class="org.apache.commons.dbcp.BasicDataSource" destroy-method="close">
        <property name="driverClassName" value="#{config['jdbc.driver']}"/>
        <property name="url" value="#{config['jdbc.url']}" />
        <property name="username" value="#{config['jdbc.username']}" />
        <property name="password" value="#{config['jdbc.password']}" />
    </bean>

    <!-- mybatis 사용을 위한 sqlSession 팩토리 빈으로 바로 위 datasouorce 빈과 config 패키지 하위 sqlConfig 설정 xml, 그리고 mapper를 모아 둔 mappers 패키지 하위 모든 xml 을 참조한다.-->
    <bean id="sqlSessionFactoryBean" class="org.mybatis.spring.SqlSessionFactoryBean">
           <property name="dataSource" ref="dataSource" />
           <property name="configLocation" value="classpath:/config/sqlConfig.xml" />
           <property name="mapperLocations" value ="classpath:/mappers/*.xml"/>
      </bean>

     <bean id="SqlSession" class="org.mybatis.spring.SqlSessionTemplate">
        <constructor-arg index="0" ref="sqlSessionFactoryBean" />
     </bean>
     <!-- <mvc:annotation-driven/>과 <context:component-scan base-package="[패키지명]"/>을 사용하기 때문에 따로 dao를 bean으로 잡지 않는다.-->

</beans>

BoardDao

 package kr.co.openeg.lab.board.dao;

import java.util.HashMap;
import java.util.List;

import [패키지명].board.model.BoardCommentModel;
import [패키지명].board.model.BoardModel;

import org.apache.ibatis.session.SqlSession;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Repository;

@Repository
public class BoardDao{

    private HashMap<String, Object> valueMap = new HashMap<String, Object>();

    //  <mvc:annotation-driven/>과 <context:component-scan base-package="[패키지명]"/>을 사용하기 때문에 @Autowired 어노테이션을 다는것 만으로 주입이 된다.
    @Autowired
    private SqlSession sqlSession;

    private static final String mapper = "[패키지명].board.dao.BoardDao";


    public List<BoardCommentModel> selectCommentList(int idx) {
        return sqlSession.selectList(mapper+".getCommentList", idx);
    }


    public void insertArticle(BoardModel board) {
            sqlSession.insert(mapper+".writeArticle", board);
    }


    public void deleteArticle(int idx) {
        sqlSession.delete(mapper+".deleteArticle", idx);
    }


    public BoardCommentModel selectOneComment(int idx) {
        return (BoardCommentModel) sqlSession.selectOne(mapper+".getOneComment", idx);
    }


    public void updateArticle(BoardModel board) {
           sqlSession.update(mapper+".modifyArticle", board);
    }

}

mybaits 기본 메서드
- selectOne
- selectList
- insert
- update
- delete

sqlConfig.xml

 <?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE configuration
    PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
    "http://mybatis.org/dtd/mybatis-3-config.dtd">

<configuration>
    <typeAliases>
        <typeAlias type="[패키지명].login.model.LoginHistory" alias="LoginHistory"/>
        <typeAlias type="[패키지명].login.model.LoginSessionModel" alias="LoginSessionModel"/>
        <typeAlias type="[패키지명].board.model.BoardCommentModel" alias="BoardCommentModel"/>
        <typeAlias type="[패키지명].board.model.BoardModel" alias="BoardModel"/>
        <typeAlias type="[패키지명].member.model.MemberModel" alias="MemberModel"/>
        <typeAlias type="[패키지명].member.model.MemberSecurity" alias="MemberSecurity"/>
    </typeAliases>

<!--     <mappers>
        <mapper resource="mappers/member.xml"/>
        <mapper resource="mappers/login.xml"/>
        <mapper resource="mappers/board.xml"/>
    </mappers>     -->
</configuration>

sqlSessionFactorybean에서 mapperLocation을 설정 했기 때문에 <mapper> 태그를 작성하지 않음
대신 model(VO,DTO)에 대한 typeAlias를 지정하여 mapper(xml)에서 사용

board.xml

 <?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE mapper
    PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
    "http://mybatis.org/dtd/mybatis-3-mapper.dtd">

<mapper namespace="[패키지명].board.dao.BoardDao">
            ...
    <select id="getCommentList" parameterType="int" resultType="BoardCommentModel">
            ...
    </select>
    <update id="modifyArticle" parameterType="BoardModel">
            ...
    </update>
</mapper>

DOCTYPE과 최상위 태그가 mapper이다.
namespace 작성이 필수이며 Dao를 풀네임으로 적는다
parameteType, resultType을 사용한다
- 여기서 사용하는 이름은 sqlConfig.xml에서 설정한 typeAlias이다.

저작자표시 동일조건

'공부 기록' 카테고리의 다른 글

[디자인패턴]Gof의 디자인패턴 (Gang of Four) (0)	2021.05.28
[객체지향] 객체지향 4대 특성 및 5대 원칙 (0)	2021.05.28
[JS] Ajax를 Axios로 변환하기 (0)	2021.05.25
[개발자의 시크릿 코드] 01_ RequestURL_Q1~5 (0)	2021.03.02
READ_ME (2021-12-29 updated) (0)	2021.02.25

내 블로그 - 관리자 홈 전환	`Q` `Q`
새 글 쓰기	`W` `W`

글 수정 (권한 있는 경우)	`E` `E`
댓글 영역으로 이동	`C` `C`

이 페이지의 URL 복사	`S` `S`
맨 위로 이동	`T` `T`
티스토리 홈 이동	`H` `H`
단축키 안내	`Shift` + `/` `⇧` + `/`

타태의 개발 일지

[JAVA] ibatis를 mybatis로 변환하기

기존 ibatis 프로젝트

pom.xml

web.xml

dispatcher-servlet

BoardDaoImpl

sqlMapConfig.xml

board.xml

Mybatis 프로젝트

pom.xml

web.xml

dispatcher-servlet

BoardDao

sqlConfig.xml

board.xml

'공부 기록' 카테고리의 다른 글

댓글

티스토리툴바

단축키

내 블로그

블로그 게시글

모든 영역

	<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 https://maven.apache.org/xsd/maven-4.0.0.xsd">
	<modelVersion>4.0.0</modelVersion>
	<groupId>[프로젝트 이름]</groupId>
	<artifactId>[프로젝트 이름]</artifactId>
	<version>0.0.1-SNAPSHOT</version>
	<packaging>war</packaging>

	<dependencies>
	<!-- https://mvnrepository.com/artifact/org.aspectj/aspectjweaver -->
	<dependency>
	<groupId>org.aspectj</groupId>
	<artifactId>aspectjweaver</artifactId>
	<version>1.9.0</version>
	</dependency>

	<!-- https://mvnrepository.com/artifact/org.springframework/spring-context -->
	<dependency>
	<groupId>org.springframework</groupId>
	<artifactId>spring-context</artifactId>
	<version>5.2.9.RELEASE</version>
	</dependency>

	<!-- https://mvnrepository.com/artifact/javax.servlet/javax.servlet-api -->
	<dependency>
	<groupId>javax.servlet</groupId>
	<artifactId>javax.servlet-api</artifactId>
	<version>3.1.0</version>
	<scope>provided</scope>
	</dependency>

	<!-- https://mvnrepository.com/artifact/javax.annotation/javax.annotation-api -->
	<dependency>
	<groupId>javax.annotation</groupId>
	<artifactId>javax.annotation-api</artifactId>
	<version>1.3.2</version>
	</dependency>

	<!-- https://mvnrepository.com/artifact/org.springframework/spring-web -->
	<dependency>
	<groupId>org.springframework</groupId>
	<artifactId>spring-web</artifactId>
	<version>5.0.7.RELEASE</version>
	</dependency>

	<!-- https://mvnrepository.com/artifact/org.springframework/spring-webmvc -->
	<dependency>
	<groupId>org.springframework</groupId>
	<artifactId>spring-webmvc</artifactId>
	<version>5.0.7.RELEASE</version>
	</dependency>

	<!-- https://mvnrepository.com/artifact/org.springframework/spring-jdbc -->
	<dependency>
	<groupId>org.springframework</groupId>
	<artifactId>spring-jdbc</artifactId>
	<version>5.0.7.RELEASE</version>
	</dependency>

	<!-- https://mvnrepository.com/artifact/org.springframework/spring-jdbc -->
	<dependency>
	<groupId>org.springframework</groupId>
	<artifactId>spring-jdbc</artifactId>
	<version>5.0.7.RELEASE</version>
	</dependency>

	<dependency>
	<groupId>org.mybatis</groupId>
	<artifactId>mybatis</artifactId>
	<version>3.2.2</version>
	</dependency>

	<dependency>
	<groupId>org.mybatis</groupId>
	<artifactId>mybatis-spring</artifactId>
	<version>1.2.0</version>
	</dependency>

	</dependencies>

	<build>
	...
	</build>
	</project>

	<?xml version="1.0" encoding="UTF-8"?>
	<web-app xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
	xmlns="http://java.sun.com/xml/ns/javaee"
	xmlns:web="http://java.sun.com/xml/ns/javaee"
	xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://java.sun.com/xml/ns/javaee/web-app_2_5.xsd"
	id="WebApp_ID"
	version="2.5">

	<display-name>[프로젝트 이름]</display-name>

	<context-param>
	<param-name>contextConfigLocation</param-name>
	<param-value>
	/WEB-INF/spring-security.xml
	</param-value>
	</context-param>

	<servlet>
	<servlet-name>dispatcher</servlet-name>
	<servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class>
	</servlet>

	<servlet-mapping>
	<servlet-name>dispatcher</servlet-name>
	<url-pattern>*.do</url-pattern>
	</servlet-mapping>


	</web-app>

	<?xml version="1.0" encoding="UTF-8"?>
	<beans xmlns="http://www.springframework.org/schema/beans"
	xmlns:context="http://www.springframework.org/schema/context"
	xmlns:mvc="http://www.springframework.org/schema/mvc"
	xmlns:p="http://www.springframework.org/schema/p"
	xmlns:aop="http://www.springframework.org/schema/aop"
	xmlns:util="http://www.springframework.org/schema/util"
	xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
	xsi:schemaLocation="http://www.springframework.org/schema/beans
	http://www.springframework.org/schema/beans/spring-beans-3.0.xsd
	http://www.springframework.org/schema/util
	http://www.springframework.org/schema/util/spring-util-3.0.xsd
	http://www.springframework.org/schema/mvc
	http://www.springframework.org/schema/mvc/spring-mvc-3.0.xsd
	http://www.springframework.org/schema/aop
	http://www.springframework.org/schema/aop/spring-aop-3.1.xsd
	http://www.springframework.org/schema/context
	http://www.springframework.org/schema/context/spring-context-3.0.xsd">

	<context:component-scan base-package="[패키지명].board.controller"/>
	<context:component-scan base-package="[패키지명].board.service"/>
	<context:component-scan base-package="[패키지명].init"/>
	<context:property-placeholder location="/WEB-INF/*.properties" />


	<!-- viewResolver -->
	<bean id="vewResolver"
	class="org.springframework.web.servlet.view.InternalResourceViewResolver">
	<property name="viewClass" value="org.springframework.web.servlet.view.JstlView" />
	<property name="prefix" value="/WEB-INF/" />
	<property name="suffix" value=".jsp" />
	</bean>

	<!-- iBatis -->
	<!-- JDBC 커넥트 관리 부분으로 config 패키지 하위 properties로 정보가 관리 되고 있었따.-->
	<util:properties id="config" location="classpath:config/dbconn.properties"/>
	<bean id="dataSource" class="org.apache.commons.dbcp.BasicDataSource" destroy-method="close">
	<property name="driverClassName" value="#{config['jdbc.driver']}"/>
	<property name="url" value="#{config['jdbc.url']}" />
	<property name="username" value="#{config['jdbc.username']}" />
	<property name="password" value="#{config['jdbc.password']}" />
	</bean>

	<bean class="org.springframework.beans.factory.config.PropertyPlaceholderConfigurer">
	<property name="locations" value="classpath:config/conn.properties;classth:config/database.properties" />
	</bean>

	<!-- ibatis 사용을 위한 SqlMapClient 팩토리 빈으로 바로 위 datasouorce 빈과 config 패키지 하위 sqlMapConfig 설정 xml을 참조 한다-->
	<bean id="sqlMapClient"
	class="org.springframework.orm.ibatis.SqlMapClientFactoryBean">
	<property name="dataSource" ref="dataSource" />
	<property name="configLocation" value="classpath:/config/sqlMapConfig.xml" />
	</bean>

	<!-- Dao classes -->
	<!-- Dao 클래스 사용을 위한 빈 생성-->
	<bean id="loginDao"
	class="[패키지명].login.dao.LoginDaoImpl"
	p:sqlMapClient-ref="sqlMapClient" />

	<bean id="memberDao"
	class="[패키지명].member.dao.MemberDaoImpl"
	p:sqlMapClient-ref="sqlMapClient" />

	<bean id="boardDao"
	class="[패키지명].board.dao.BoardDaoImpl"
	p:sqlMapClient-ref="sqlMapClient" />


	</beans>

	package kr.co.openeg.lab.board.dao;

	import java.util.HashMap;
	import java.util.List;

	import [패키지명].board.model.BoardCommentModel;
	import [패키지명].board.model.BoardModel;

	import org.springframework.jdbc.core.support.JdbcDaoSupport;
	import org.springframework.orm.ibatis.support.SqlMapClientDaoSupport;


	public class BoardDaoImpl extends SqlMapClientDaoSupport implements BoardDao {

	private HashMap<String, Object> valueMap = new HashMap<String, Object>();


	@Override
	public List<BoardCommentModel> selectCommentList(int idx) {
	return getSqlMapClientTemplate().queryForList("board.getCommentList", idx);
	}

	@Override
	public void insertArticle(BoardModel board) {
	getSqlMapClientTemplate().insert("board.writeArticle", board);
	}

	@Override
	public void deleteArticle(int idx) {
	getSqlMapClientTemplate().delete("board.deleteArticle", idx);
	}

	@Override
	public BoardCommentModel selectOneComment(int idx) {
	return (BoardCommentModel) getSqlMapClientTemplate().queryForObject("board.getOneComment", idx);
	}

	@Override
	public void updateArticle(BoardModel board) {
	getSqlMapClientTemplate().update("board.modifyArticle", board);
	}

	}

	<?xml version="1.0" encoding="UTF-8" ?>
	<!DOCTYPE sqlMapConfig
	PUBLIC "-//ibatis.apache.org//DTD SQL Map Config 2.0//EN"
	"http://ibatis.apache.org/dtd/sql-map-config-2.dtd">

	<sqlMapConfig>
	<settings useStatementNamespaces="true" />
	<sqlMap resource="[패키지명]/member/dao/member.xml" />
	<sqlMap resource="[패키지명]/board/dao/board.xml" />
	<sqlMap resource="[패키지명]/login/dao/login.xml" />
	</sqlMapConfig>

	<?xml version="1.0" encoding="UTF-8" ?>
	<!DOCTYPE sqlMap
	PUBLIC "-//ibatis.apache.org//DTD SQL Map 2.0//EN"
	"http://ibatis.apache.org/dtd/sql-map-2.dtd">

	<sqlMap namespace="board">
	<typeAlias alias="BoardModel" type="[패키지명].board.model.BoardModel"/>
	<typeAlias alias="BoardCommentModel" type="[패키지명].board.model.BoardCommentModel"/>
	...
	<select id="loginCheck" parameterClass="String" resultClass="LoginModel">
	...
	</select>


	</sqlMap>

	<project xmlns="http://maven.apache.org/POM/4.0.0"
	xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
	xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
	https://maven.apache.org/xsd/maven-4.0.0.xsd">

	<modelVersion>4.0.0</modelVersion>
	<groupId>[프로젝트명]</groupId>
	<artifactId>[프로젝트명]</artifactId>
	<version>0.0.1-SNAPSHOT</version>
	<packaging>war</packaging>


	<dependencies>
	<dependency>
	<groupId>javax.servlet</groupId>
	<artifactId>jstl</artifactId>
	<version>1.2</version>
	</dependency>
	<dependency>
	<groupId>javax.servlet.jsp</groupId>
	<artifactId>javax.servlet.jsp-api</artifactId>
	<version>2.3.0</version>
	<scope>provided</scope>
	</dependency>
	<dependency>
	<groupId>javax.el</groupId>
	<artifactId>javax.el-api</artifactId>
	<version>2.2.2</version>
	<scope>provided</scope>
	</dependency>
	<!-- https://mvnrepository.com/artifact/org.aspectj/aspectjweaver -->
	<dependency>
	<groupId>org.aspectj</groupId>
	<artifactId>aspectjweaver</artifactId>
	<version>1.9.0</version>
	</dependency>

	<!-- https://mvnrepository.com/artifact/org.springframework/spring-context -->
	<dependency>
	<groupId>org.springframework</groupId>
	<artifactId>spring-context</artifactId>
	<version>5.2.9.RELEASE</version>
	</dependency>

	<!-- https://mvnrepository.com/artifact/javax.servlet/javax.servlet-api -->
	<dependency>
	<groupId>javax.servlet</groupId>
	<artifactId>javax.servlet-api</artifactId>
	<version>3.1.0</version>
	<scope>provided</scope>
	</dependency>

	<!-- https://mvnrepository.com/artifact/javax.annotation/javax.annotation-api -->
	<dependency>
	<groupId>javax.annotation</groupId>
	<artifactId>javax.annotation-api</artifactId>
	<version>1.3.2</version>
	</dependency>

	<!-- https://mvnrepository.com/artifact/org.springframework/spring-web -->
	<dependency>
	<groupId>org.springframework</groupId>
	<artifactId>spring-web</artifactId>
	<version>5.0.7.RELEASE</version>
	</dependency>

	<!-- https://mvnrepository.com/artifact/org.springframework/spring-webmvc -->
	<dependency>
	<groupId>org.springframework</groupId>
	<artifactId>spring-webmvc</artifactId>
	<version>5.0.7.RELEASE</version>
	</dependency>

	<!-- https://mvnrepository.com/artifact/org.springframework/spring-jdbc -->
	<dependency>
	<groupId>org.springframework</groupId>
	<artifactId>spring-jdbc</artifactId>
	<version>5.0.7.RELEASE</version>
	</dependency>

	<dependency>
	<groupId>commons-dbcp</groupId>
	<artifactId>commons-dbcp</artifactId>
	<version>1.4</version>
	</dependency>

	<dependency>
	<groupId>org.mybatis</groupId>
	<artifactId>mybatis-spring</artifactId>
	<version>1.3.2</version>
	</dependency>

	<dependency>
	<groupId>org.mybatis</groupId>
	<artifactId>mybatis</artifactId>
	<version>3.4.6</version>
	</dependency>

	<!-- Spring Security -->
	<dependency>
	<groupId>org.springframework.security</groupId>
	<artifactId>spring-security-core</artifactId>
	<version>4.1.3.RELEASE</version>
	</dependency>
	<dependency>
	<groupId>org.springframework.security</groupId>
	<artifactId>spring-security-web</artifactId>
	<version>4.1.3.RELEASE</version>
	</dependency>
	<dependency>
	<groupId>org.springframework.security</groupId>
	<artifactId>spring-security-config</artifactId>
	<version>4.1.3.RELEASE</version>
	</dependency>
	<dependency>
	<groupId>org.springframework.security</groupId>
	<artifactId>spring-security-taglibs</artifactId>
	<version>4.1.3.RELEASE</version>
	</dependency>


	<!-- https://mvnrepository.com/artifact/mysql/mysql-connector-java -->
	<dependency>
	<groupId>mysql</groupId>
	<artifactId>mysql-connector-java</artifactId>
	<version>8.0.22</version>
	</dependency>


	</dependencies>

	<build>
	...
	</build>
	</project>

	<?xml version="1.0" encoding="UTF-8"?>
	<!DOCTYPE configuration
	PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
	"http://mybatis.org/dtd/mybatis-3-config.dtd">

	<configuration>
	<typeAliases>
	<typeAlias type="[패키지명].login.model.LoginHistory" alias="LoginHistory"/>
	<typeAlias type="[패키지명].login.model.LoginSessionModel" alias="LoginSessionModel"/>
	<typeAlias type="[패키지명].board.model.BoardCommentModel" alias="BoardCommentModel"/>
	<typeAlias type="[패키지명].board.model.BoardModel" alias="BoardModel"/>
	<typeAlias type="[패키지명].member.model.MemberModel" alias="MemberModel"/>
	<typeAlias type="[패키지명].member.model.MemberSecurity" alias="MemberSecurity"/>
	</typeAliases>

	<!-- <mappers>
	<mapper resource="mappers/member.xml"/>
	<mapper resource="mappers/login.xml"/>
	<mapper resource="mappers/board.xml"/>
	</mappers> -->
	</configuration>

	<?xml version="1.0" encoding="UTF-8"?>
	<!DOCTYPE mapper
	PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
	"http://mybatis.org/dtd/mybatis-3-mapper.dtd">

	<mapper namespace="[패키지명].board.dao.BoardDao">
	...
	<select id="getCommentList" parameterType="int" resultType="BoardCommentModel">
	...
	</select>
	<update id="modifyArticle" parameterType="BoardModel">
	...
	</update>
	</mapper>

[JAVA] ibatis를 mybatis로 변환하기

기존 ibatis 프로젝트

pom.xml

web.xml

dispatcher-servlet

BoardDaoImpl

sqlMapConfig.xml

board.xml

Mybatis 프로젝트

pom.xml

web.xml

dispatcher-servlet

BoardDao

sqlConfig.xml

board.xml

'공부 기록' 카테고리의 다른 글

관련글

댓글

티스토리툴바

단축키

내 블로그

블로그 게시글

모든 영역
